Migrating from Legacy Lead Activity Data Stream to Adobe I/O Lead Activity Data Stream

This guide provides comprehensive instructions for migrating customers from the legacy Lead Activity Data Stream to the new Adobe I/O Lead Activity Data Stream (LADS).

Does this affect me?

This migration affects only a very small subset of customers who were onboarded to the Lead Activity Data Stream before it was integrated with Adobe I/O Events. If you are a newer data streams customer or already manage the Lead Activity Data Stream via I/O Events, this will have no impact on you.

We have reached out to all customers still using the legacy version of the stream to coordinate migration and will make sure to reach out again as a reminder of the action needed. Also, to clarify, this only affects the Lead Activity Data Stream, and no other Marketo Data Streams are affected.

If you think this might affect you, but are unsure, feel free to reach out to your account/support teams, and we will help confirm.

Overview

The migration enables enhanced reliability, CloudEvents format, scalability, minimal downtime, better monitoring, and self-service capabilities.

Migration Process Overview

The following diagram illustrates the suggested end-to-end migration process:

Migration Process

Key Differences: Legacy vs Adobe I/O LADS

Understanding the differences between the legacy and new systems is critical for a successful migration:

Aspect
Legacy Activity Push
Adobe I/O LADS
Migration Impact
Payload Structure
Custom Marketo format with batch wrapper
CloudEvents specification (v1.0)
Yes
Authentication
OAuth validation
Adobe I/O Digital Signature and mTLS
Yes
Monitoring
Basic delivery confirmation
Debug tracing, event browser, journaling
No
Data History
No historical data access
7-day journaling with API access
No

Pre-Migration Requirements

Adobe I/O Project Configuration

Required Actions: When setting up a project to subscribe to events, there are four differnet ways to interact with those event subscriptions.

The Journaling is always available by default, which provides a pull model in which events can be pulled via API and stores up to 7 days of past events. In addition to this, you can optionally choose one of the below options:

  1. Webhooks, which can be configured to send events either as single events or batched to a webhook endpoint in near real-time with the event occurrence.
  2. Runtime, where you can set up your own custom function within Adobe that events will automatically run through near-real time.
  3. AWS Event Bridge, which enables you to route events between your own applications, third-party SaaS applications, and AWS services. For more information, refer to Adobe Developer Docs for Event Bridge

Depending on the mechanism, the following actions are required.

Prerequisites:

Webhook Receiving Service Updates

Your webhook receiving service must be updated to handle the new payload structure.

Legacy Payload Structure

The legacy system sends activities in a batch wrapper format:

{
    "sourceApplication": "Marketo",
    "munchkinId": "123-ABC-456",
    "messageId": "12345",
    "messageCreatedDate": "2026-04-21T15:28:49Z",
    "activities": [
        {
            "marketoGUID": "12345678-9876-a191-4567-000000054321",
            "leadId": 12345,
            "activityDate": "2026-04-20T18:43:56Z",
            "primaryAttributeValueId": 1234,
            "primaryAttributeValue": "Attribute Value",
            "activityTypeId": 3,
            "activityType": "Click Link",
            "activityLogItemId": 1234567890,
             "attributes": [
                {
                  "name": "Link ID",
                  "dataType": "object",
                  "value": 1234
                },
                {
                  "name": "Client IP Address",
                  "dataType": "string",
                  "value": "11.22.33.44"
                }
              ]
        }
    ]
}

New Adobe I/O LADS Payload Structure

The new system uses the CloudEvents specification. See Setting up Marketo Lead Activity Data Stream for more details.

{
  "eventid": "4109a990-da28-4c5b-bad9-22df8903ed9a",
  "specversion": "1.0",
  "type": "com.adobe.platform.marketo.activity.standard.clicklink",
  "source": "urn:marketo_activity_stream",
  "id": "12345678-9876-a191-4567-000000054321",
  "time": "2026-04-21T15:28:49Z",
  "datacontenttype": "application/json",
  "data": {
    "munchkinId": "123-ABC-456",
    "leadId": "12345",
    "activityDate": "2026-04-20T18:43:56Z",
    "activityTypeId": 3,
    "activityType": "Click Link",
    "activityLogItemId": 1234567890,
    "primaryAttributeValueId": 1234,
    "primaryAttributeValue": "Attribute Value",
    "attributes": [
      {
        "name": "Link ID",
        "dataType": "object",
        "value": 1234
      },
      {
        "name": "Client IP Address",
        "dataType": "string",
        "value": "11.22.33.44"
      }

    ]
  },
  "recipientclientid": "<your_client_id>"
}

Key Mapping Changes

When updating your service, note these field mappings:

Migration Cutover Strategy

The safest migration approach involves running both systems in parallel before switching over.

Phase 1: Dual Stream

Phase 2: Gradual Cutover

Data Loss Prevention

Data Loss Prevention Strategy

1. Overlap Window

2. Journaling Utilization

3. Rollback Plan

Journal Recovery Example

If you need to recover events from journaling:

#!/bin/bash
# Recover events from Adobe I/O Journaling API

JOURNAL_URL="https://api.adobe.io/events/organizations/{orgId}/integrations/{integrationId}/journal"
ACCESS_TOKEN="your_access_token"
FROM_POSITION="last_known_position"

curl -X GET \
  https://events-va6.adobe.io/organizations/xxxxx/integrations/xxxx/xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx \
  -H "x-ims-org-id: $ORG_ID" \
  -H "Authorization: Bearer $oauth_s2s_token" \
  -H "x-api-key: $API_KEY"

  | jq '.events[] | .event' \
  | while read -r event; do
    # Process recovered event
    curl -X POST "https://your-endpoint.com/webhook" \
      -H "Content-Type: application/json" \
      -d "$event"
  done

Refer to Journaling API for details

Migration Activities and Phases

Phase
Activities
Owner
Success Criteria
Assessment
Audit current integration; Identify payload dependencies; Plan service updates
Customer + Adobe
Migration plan approved
Development
Create new receiving service for Adobe I/O Webhook integration; Set up Adobe I/O project
Customer
Test environment working
Testing
Parallel stream validation; New receiving service used for validation but not integrated with first-party systems; Load testing; Failure scenario testing
Customer + Adobe
100% data accuracy
Cutover
Legacy stream shutdown; Production cutover with new receiving service integrated with first-party systems; 48-hour monitoring
Customer + Adobe
Zero data loss
Stabilization
Performance optimization; Documentation update
Customer
Stable operations

Failure Handling and Recovery

Understanding how to handle failures ensures minimal disruption during and after migration.

Scenario
Detection Method
Immediate Response
Recovery Action
Webhook Failure
HTTP 5xx responses, timeouts
Automatic retry with exponential backoff; Automatic email notification to project admin
Fix endpoint, fetch from journal
Adobe I/O Outage
No events received for >1 hour
Alert operations team
Use journaling to recover missed events
Payload Corruption
JSON parsing errors
Log error, continue processing
Refer to sample events to confirm structure

Post-Migration Benefits

After completing the migration, you'll gain access to several enhanced capabilities:

Support and Resources

Migration Support
