Structure Reference Images

Use Structure Reference to generate images with structural similarities.

Structure Reference Image	Generated Image

Understanding Firefly's Structure Reference

Structure Reference uses a reference image to apply structural characteristics (like image outline and depth) to newly generated images with different details, styles, or moods. This feature, along with Firefly's Style Reference, gives you more control of image generation beyond the text prompt.

Firefly's Image APIs implement this feature by using the structure parameter, with two properties:

• strength: A value between 1 and 100 that determines how closely the generated image resembles the reference image. When strength isn't specified, the default value is 50.
• imageReference: An object containing the source for the reference image.

Concepts in action

Specifying strength

Use the strength value to influence the resemblance of newly generated images.

1. First, let's use the reference image of the mountain from the example at the top of this page. Right-click the "Structure Reference Image" and save it to your desktop.

2. Next, upload the saved image to Firefly's storage API. Be sure to edit the --data-binary path in the command below:

Copy
curl --location 'https://firefly-api.adobe.io/v2/storage/image' \
--header 'Content-Type: image/webp' \
--header 'Accept: application/json' \
--header "x-api-key: $FIREFLY_SERVICES_CLIENT_ID" \
--header "Authorization: Bearer $FIREFLY_SERVICES_ACCESS_TOKEN" \
--data-binary '@/Users/<YOUR_MACHINE_USER_NAME>/Desktop/structure-image-reference-mountain.webp'
Copied to your clipboard
curl --location 'https://firefly-api.adobe.io/v2/storage/image' \
--header 'Content-Type: image/webp' \
--header 'Accept: application/json' \
--header "x-api-key: $FIREFLY_SERVICES_CLIENT_ID" \
--header "Authorization: Bearer $FIREFLY_SERVICES_ACCESS_TOKEN" \
--data-binary '@/Users/<YOUR_MACHINE_USER_NAME>/Desktop/structure-image-reference-mountain.webp'

The response will look like this:

Copy
{"images":[{"id":"0eb8584a-b850-4c4c-a234-185d6378ecb6"}]}  //Your images.id here will be unique
Copied to your clipboard
{"images":[{"id":"0eb8584a-b850-4c4c-a234-185d6378ecb6"}]}  //Your images.id here will be unique

3. Export the ID so that the next script can easily access it:

Copy
export FIREFLY_UPLOAD_ID=<YOUR_images.id>
Copied to your clipboard
export FIREFLY_UPLOAD_ID=<YOUR_images.id>

4. Generate a new image based on the uploaded image. Use the command below to see how the strength parameter influences the resemblance of the generated image. Start with a strength value of 100, then experiment with other values.

Copy
curl --location 'https://firefly-api.adobe.io/v3/images/generate-async' \
--header 'Content-Type: application/json' \
--header 'Accept: application/json' \
--header "x-api-key: $FIREFLY_SERVICES_CLIENT_ID" \
--header "Authorization: Bearer $FIREFLY_SERVICES_ACCESS_TOKEN" \
--data '{
  "numVariations": 4,
  "prompt": "a photo of a volcano",
  "structure": {
    "strength": 100,
    "imageReference": {
      "source": {
        "uploadId": "'$FIREFLY_UPLOAD_ID'"
      }
    }
  }
}'
Copied to your clipboard
curl --location 'https://firefly-api.adobe.io/v3/images/generate-async' \
--header 'Content-Type: application/json' \
--header 'Accept: application/json' \
--header "x-api-key: $FIREFLY_SERVICES_CLIENT_ID" \
--header "Authorization: Bearer $FIREFLY_SERVICES_ACCESS_TOKEN" \
--data '{
  "numVariations": 4,
  "prompt": "a photo of a volcano",
  "structure": {
    "strength": 100,
    "imageReference": {
      "source": {
        "uploadId": "'$FIREFLY_UPLOAD_ID'"
      }
    }
  }
}'

The request returns a rapid response for the asynchronous job:

Copy
{
    "jobId":"<YOUR_JOB_ID>",
    "statusUrl":"https://firefly-epo854211.adobe.io/v3/status/urn:ff:jobs:...",
    "cancelUrl":"https://firefly-epo854211.adobe.io/v3/cancel/urn:ff:jobs:..."
}
Copied to your clipboard
{
    "jobId":"<YOUR_JOB_ID>",
    "statusUrl":"https://firefly-epo854211.adobe.io/v3/status/urn:ff:jobs:...",
    "cancelUrl":"https://firefly-epo854211.adobe.io/v3/cancel/urn:ff:jobs:..."
}

5. Use the jobId to see the result:

Copy
curl -X GET "https://firefly-api.adobe.io/v3/status/<YOUR_JOB_ID>" \
    -H "x-api-key: $FIREFLY_SERVICES_CLIENT_ID" \
    -H "Authorization: Bearer $FIREFLY_SERVICES_ACCESS_TOKEN" \
    -H "Content-Type: application/json"
Copied to your clipboard
curl -X GET "https://firefly-api.adobe.io/v3/status/<YOUR_JOB_ID>" \
    -H "x-api-key: $FIREFLY_SERVICES_CLIENT_ID" \
    -H "Authorization: Bearer $FIREFLY_SERVICES_ACCESS_TOKEN" \
    -H "Content-Type: application/json"
