Fieldset component

The Fieldset component implements a container for visually-grouped form elements, such as buttons and form fields.

Options

Title
Type
Default
Description
disabled
Boolean
false
Initial component's state. When true, users cannot take action on the element.
label
String
Caption for an item in the UI component context.
visible
Boolean
true
Initial component's visibility. When set to false, the display: none CSS style is added to the component's DOM block.
additionalClasses
Object
{}
Custom classes added to the component's DOM block.
level
Integer
Explicitly indicates the level of nesting([date-level] attribute).

collapsible configuration

Title
Type
Default
Description
collapsible
Boolean
false
Enables/disables the collapsible functionality.
label
String
Caption for the fieldset.
opened
Boolean
false
Initial collapsible state. Applied when the collapsible functionality is enabled.

Examples

Integration

The following example adds a new main fieldset that contains a collapsible fieldset into the Form component:

<form>
    <fieldset name="main_fieldset">
        <settings>
            <label translate="true">Other Settings</label>
        </settings>
        <fieldset name="fieldset_group">
            <argument name="data" xsi:type="array">
                <item name="config" xsi:type="array">
                    <item name="label" xsi:type="string" translate="true">Information</item>
                    <item name="collapsible" xsi:type="boolean">true</item>
                    <item name="opened" xsi:type="boolean">true</item>
                </item>
            </argument>
            <field name="my_field">
                <argument name="data" xsi:type="array">
                    <item name="config" xsi:type="array">
                        <item name="label" xsi:type="string" translate="true">My Field</item>
                        <item name="visible" xsi:type="boolean">true</item>
                        <item name="dataType" xsi:type="string">text</item>
                        <item name="formElement" xsi:type="string">input</item>
                    </item>
                </argument>
            </field>
        </fieldset>
    </fieldset>
</form>

Result

Checkbox UiComponent

Source files

Extends uiCollection and collapsible:
